Associated Spring Raymond - 77.39mm ID x 99.49mm OD, Grade 1074 High Carbon Steel Triple Wave Washer - 1.07mm Thick, 6.55mm Overall Height, 3.3mm Deflection, 98 Lb at Deflection
Item #: 69130060
Brand: Associated Spring Raymond
Model #: W3917042
Exact Tooling IR#: 04
Features and Benefits
Triple wave washers have a greater load-bearing capacity than single wave washers but have a smaller diameter.
High carbon steel (HCS) is harder than plain carbon steel and has a high tensile strength. It is commonly used on wood, ferrous and non-ferrous metals.
| Product Specifications | |
|---|---|
| Type | Triple Wave Washer |
| System of Measurement | Inch |
| Inside Diameter (mm) | 77.39 |
| Inside Diameter (Decimal Inch) | 3.047 |
| Outside Diameter (mm) | 99.49 |
| Outside Diameter (Decimal Inch) | 3.917 |
| Material | High Carbon Steel |
| Material Grade | 1074 |
| Overall Height (Decimal Inch) | 0.258 |
| Overall Height (mm) | 6.55 |
| Thickness (Decimal Inch) | 0.042 |
| Thickness (mm) | 1.07 |
| Deflection (Decimal Inch) | 0.1300 |
| Load at Deflection (Lb.) | 98.00 |
| Deflection (mm) | 3.30 |
| Load at Deflection (N) | 436 |
