Circuit Breakers; Circuit Breaker Type: Miniature Circuit Breaker; Amperage: 25; Voltage: 347V, 600V; Wire Size (AWG): 12-6 (Aluminum)/14-6 (Copper); Number Of Poles: 2; Tripping Mechanism: Thermal-Magnetic; Terminal Connection Type: Lug; Phase: Single
Item #: 93312791
Brand: Square D
Model #: EGB26025
Product Specifications
| Circuit Breaker Type | Miniature Circuit Breaker |
| Amperage | 25 |
| Voltage | 347V; 600V |
| Wire Size (AWG) | 12-6 (Aluminum)/14-6 (Copper) |
| Number Of Poles | 2 |
| Tripping Mechanism | Thermal-Magnetic |
| Terminal Connection Type | Lug |
| Phase | Single |
| Breaking Capacity | 18 kA |
| Mount Type | Bolt-On |
| Maximum Operating Temperature F | 122.000 |
| Minimum Operating Temperature F | 32.000 |
| Overall Length (Decimal Inch) | 4.0500 |
| Overall Width (Decimal Inch - 4 Decimals) | 1.9600 |
| Overall Height (Decimal Inch) | 5.6600 |
| Standards | cULus |
| UNSPSC Code | 39121603 |
