Indexable Drill Insert: WDXT073506M ACM300, Carbide
Item #: 97716633
Brand: Sumitomo
Model #: 1A4W996
Product Specifications
| Insert Style | WDXT |
| Insert Material | Carbide |
| Manufacturer Grade | ACM300 |
| Thickness (mm) | 3.50 |
| Corner Radius (mm) | 0.60 |
| Chipbreaker | M |
| Series | WDX |
| Coating Process | PVD |
| Shape | Diamond |
| Number Of Cutting Edges | 2 |
| Relief Angle | 11 |
| Rake | Positive |
| Ansi Code | WDXT073506 ACM300 |
| Insert Size | 073506 |
| Width (mm - 2 Decimals) | 7.5 |
| Length (Mm) | 8.25 |
| Included Angle Degree | 80 |
| Coating/Finish | AlCrN; TiAlN |
| Insert Size Code | 073506 |
| Insert Hand | Neutral |
| UNSPSC Code | 23242105 |
