Associated Spring Raymond - 25mm Hole Diam, 12.5mm Rod Diam, 1" Free Length, Blue Die Spring - 1381.8 N Max Deflection, 9.4mm Max Deflection, Medium Duty, Chromium Alloy Steel
Item #: 67899773
Brand: Associated Spring Raymond
Model #: 204-504
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hole Diameter (mm) | 25.00 |
| Rod Diameter (mm) | 12.50 |
| Free Length (mm) | 25.00 |
| Free Length (Inch) | 1 |
| Load Type | Medium-Duty |
| Color | Blue |
| Maximum Deflection Load (N) | 1381.80 |
| Maximum Deflection (mm) | 9.40 |
| Travel To Solid Load (mm) | 9.40 |
| Wire Shape | Trapezoidal |
| Material | Chromium Alloy Steel |
| ISO Number | 10243 |
