Associated Spring Raymond - 16mm Hole Diam, 8mm Rod Diam, 3-1/2" Free Length, Blue Die Spring - 513.8 N Max Deflection, 33.8mm Max Deflection, Medium Duty, Chromium Alloy Steel - Apex Tool & Supply

Associated Spring Raymond - 16mm Hole Diam, 8mm Rod Diam, 3-1/2" Free Length, Blue Die Spring - 513.8 N Max Deflection, 33.8mm Max Deflection, Medium Duty, Chromium Alloy Steel


Item #: 67899609
Brand: Associated Spring Raymond
Model #: 204-314
Exact Tooling IR#: 04

Product Specifications
Hole Diameter (mm) 16.00
Rod Diameter (mm) 8.00
Free Length (mm) 89.00
Free Length (Inch) 3-1/2
Load Type Medium-Duty
Color Blue
Maximum Deflection Load (N) 513.80
Maximum Deflection (mm) 33.80
Travel To Solid Load (mm) 33.80
Wire Shape Trapezoidal
Material Chromium Alloy Steel
ISO Number 10243
$5.75
