Straight Flute Tap: M3 M, 3 Flute, Bottoming Chamfer, 6HX Class of Fit, Powdered Metal HSS, ta-C (DLC) Finish
Item #: 02217164
Brand: Sandvik Coromant
Model #: 8330269
Product Specifications
| Tap Type | Straight Flute |
| Thread Size (mm) | M3 |
| Thread Standard | M |
| Chamfer | Bottoming |
| Material | Powdered Metal High-Speed Steel |
| Coating/Finish | ta-C (DLC) |
| Thread Direction | Right Hand |
| Coolant Through | No |
| Class Of Fit | 6HX |
| Number Of Flutes | 3 |
| Overall Length (Decimal Inch) | 1.8110 |
| Overall Length (mm) | 46 |
| Thread Length (Decimal Inch) | 0.3937 |
| Thread Length (mm) | 10.00 |
| Application | Blind Hole Threading; Through-Hole Threading |
| Shank Diameter (mm) | 4.0000 |
| Shank Diameter (Decimal Inch) | 0.1575 |
| Tapping Depth (mm) | 18.00 |
| Tapping Depth (Decimal Inch) | 0.7087 |
| Material Application | Non-Ferrous Metal |
| Series | CoroTap™ 100 |
| UNSPSC Code | 23291800 |
