Sleeve Bearings; Bearing Type: Flanged; Outside Diameter (Inch): 1-1/8; Outside Diameter (Decimal Inch - 4 Decimals): 1.1250; Inside Diameter (Inch): 1; Inside Diameter (Decimal Inch): 1.0000
Item #: 76805795
Brand: USA Industrials
Model #: ZUSAB-PB-1086
Product Specifications
| Bearing Type | Flanged |
| Outside Diameter (Inch) | 1-1/8 |
| Outside Diameter (Decimal Inch - 4 Decimals) | 1.1250 |
| Inside Diameter (Inch) | 1 |
| Inside Diameter (Decimal Inch) | 1.0000 |
| Flange Outside Diameter (Decimal Inch) | 1.3750 |
| Flange Outside Diamete (mm) | 34.93 |
| Flange Outside Diameter (Inch) | 1-3/8 |
| Flange Thickness (Decimal Inch) | 0.0625 |
| Flange Thickness (Inch) | 1/16 |
| Material | Steel |
| Overall Length (Inch) | 1 |
| Overall Length (Decimal Inch) | 1.0000 |
| Static Load Capacity | 200234.99 |
| Dynamic Load Capacity | 2923960.790 |
| Maximum Pressure X Velocity | 406 |
| Bore Type | Plain |
| Lubricant Type | PTFE |
| Temperature Range | -320 to 530 Deg F |
| Housing Bore Limits Maximum | 1.1260 |
| Housing Bore Limits Mininum | 1.1250 |
| Flange Thickness (mm) | 1.59 |
| Inside Diameter (mm) | 25.4000 |
| Overall Length (mm) | 25.4 |
| UNSPSC Code | 31171501 |
| Country of Origin | United Kingdom |
