Accurate Bushing - 1-1/4" Roller Diam x 3/4" Width, 1/2" Stud Diam x 1-1/4" Length, Sealed Self Lubricating Stud Cam Follower with Nonmetallic Bushing - Carbon Steel, 5/8" Thread Length, 1/2-20 Thread, 2" OAL
Item #: 62902002
Brand: Accurate Bushing
Model #: BCR-1-1/4-X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Self-Lubricating Stud Cam Follower with Non-Metallic Bushing |
| Roller Diameter (Decimal Inch) | 1.2500 |
| Roller Diameter (Inch) | 1-1/4 |
| Roller Width (Decimal Inch) | 0.7500 |
| Stud Diameter (Decimal Inch) | 0.5000 |
| Dynamic Load Capacity (N) | 0 |
| Static Load Capacity | 0 |
| Length (Decimal Inch) | 2.000 |
| Thread Size | 1/2-20 |
| Material | Carbon Steel |
| Stud Length (Decimal Inch) | 1.2500 |
| Stud Length (Inch) | 1-1/4 |
| Thread Length (Inch) | 5/8 |
