Associated Spring Raymond - #12 Bolt, Grade 17-7 PH Stainless Steel, Uncoated, Belleville Disc Spring - 0.043" High, 0.018" Thick
Item #: 61411179
Brand: Associated Spring Raymond
Model #: BC0437018S
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Bolt Size (mm) | 5.59 |
| Screw Size (Wire) | #12 |
| System of Measurement | Inch |
| Material | Stainless Steel |
| Material Grade | 17-7 PH |
| Thickness (mm) | 0.46 |
| Thickness (Decimal Inch) | 0.0180 |
| Overall Height (mm) | 1.09 |
| Overall Height (Decimal Inch) | 0.0430 |
| Deflection (Decimal Inch) | 0.0190 |
| Deflection (mm) | 0.48 |
| Minimum Inside Diameter (Decimal Inch) | 0.2200 |
| Minimum Inside Diameter (mm) | 5.59 |
| Maximum Outside Diameter (Decimal Inch) | 0.4370 |
| Maximum Outside Diameter (mm) | 11.10 |
| Load at Flat (Lb.) | 71.00 |
| Load at Flat (N) | 315.82 |
| Minimum Load at Deflection (Lb.) | 36.00 |
| Minimum Load at Deflection (N) | 160.14 |
| Maximum Load at Deflection (Lb.) | 54.00 |
| Maximum Load at Deflection (N) | 240.20 |
| Finish/Coating | Uncoated |
| Bolt Size (Decimal Inch) | 0.2200 |
