Associated Spring Raymond - #8 Bolt, Grade 17-7 PH Stainless Steel, Uncoated, Belleville Disc Spring - 0.034" High, 0.014" Thick
Item #: 61411138
Brand: Associated Spring Raymond
Model #: BC0343014S
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Bolt Size (mm) | 4.17 |
| Screw Size (Wire) | #8 |
| System of Measurement | Inch |
| Material | Stainless Steel |
| Material Grade | 17-7 PH |
| Thickness (mm) | 0.36 |
| Thickness (Decimal Inch) | 0.0140 |
| Overall Height (mm) | 0.86 |
| Overall Height (Decimal Inch) | 0.0340 |
| Deflection (Decimal Inch) | 0.0150 |
| Deflection (mm) | 0.38 |
| Minimum Inside Diameter (Decimal Inch) | 0.1690 |
| Minimum Inside Diameter (mm) | 4.29 |
| Maximum Outside Diameter (Decimal Inch) | 0.3430 |
| Maximum Outside Diameter (mm) | 8.71 |
| Load at Flat (Lb.) | 35.00 |
| Load at Flat (N) | 155.69 |
| Minimum Load at Deflection (Lb.) | 23.90 |
| Minimum Load at Deflection (N) | 106.31 |
| Maximum Load at Deflection (Lb.) | 35.90 |
| Maximum Load at Deflection (N) | 159.69 |
| Finish/Coating | Uncoated |
| Bolt Size (Decimal Inch) | 0.1640 |
