Associated Spring Raymond - #10 Bolt, Grade 17-7 PH Stainless Steel, Uncoated, Belleville Disc Spring - 0.039" High, 0.018" Thick
Item #: 61403598
Brand: Associated Spring Raymond
Model #: BC0375018S
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Bolt Size (mm) | 4.95 |
| Screw Size (Wire) | #10 |
| System of Measurement | Inch |
| Material | Stainless Steel |
| Material Grade | 17-7 PH |
| Thickness (mm) | 0.46 |
| Thickness (Decimal Inch) | 0.0180 |
| Overall Height (mm) | 0.99 |
| Overall Height (Decimal Inch) | 0.0390 |
| Deflection (Decimal Inch) | 0.0160 |
| Deflection (mm) | 0.41 |
| Minimum Inside Diameter (Decimal Inch) | 0.1950 |
| Minimum Inside Diameter (mm) | 4.95 |
| Maximum Outside Diameter (Decimal Inch) | 0.3750 |
| Maximum Outside Diameter (mm) | 9.53 |
| Load at Flat (Lb.) | 64.00 |
| Load at Flat (N) | 284.69 |
| Minimum Load at Deflection (Lb.) | 32.80 |
| Minimum Load at Deflection (N) | 145.90 |
| Maximum Load at Deflection (Lb.) | 49.40 |
| Maximum Load at Deflection (N) | 219.74 |
| Finish/Coating | Uncoated |
| Bolt Size (Decimal Inch) | 0.1950 |
