McGill - 72mm Roller Diam x 29mm Width, 24mm Stud Diam x 50mm Length, Crowned Stud Cam Follower - Steel, 25mm Thread Length, M24x1.5 Thread, 80mm OAL, 8,732 Lb Dynamic Cap, 14,703 Lb Static Cap
Item #: 57967606
Brand: McGill
Model #: MCF 72
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Crowned Stud Cam Follower |
| Roller Diameter (mm) | 72.000 |
| Roller Width (mm) | 29 |
| Stud Diameter (mm) | 24.00 |
| Dynamic Load Capacity (Lb.) | 8732 |
| Dynamic Load Capacity (N) | 38840 |
| Static Load Capacity (Pounds) | 14703.00 |
| Static Load Capacity | 65400 |
| Length (mm) | 80.00 |
| Thread Size | M24x1.5 |
| Material | Steel |
| Stud Length (mm) | 50.00 |
| Thread Length (mm) | 25.00 |
| Roller Type | Full Complement |
