Pentair - ODP Motor, 115/208-230 Volt, 1 Phase, 1/2 HP, Cast Iron Straight Pump - 1-1/4 Inch Inlet, 1 Inch Outlet, 82 Max Head psi, Bronze Impeller, Cast Iron Shaft, Viton Seal, 82 Ft. Shut Off
Item #: 56610611
Brand: Pentair
Model #: CHMCV12
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Current Type | Centrifugal |
| Input Voltage | 115/208-230 |
| Phase | 1 |
| Horsepower | 1/2 |
| Motor Type | ODP |
| Inlet Size (Inch) | 1-1/4 |
| Outlet Size (Inch) | 1 |
| Maximum Flow Rate (GPM) | 82.00 |
| Maximum Head Pressure | 82.0 |
| Housing Material | Cast Iron |
| Impeller Material | Bronze |
| Shaft Material | Cast Iron |
| Seal Material | Viton |
| Seal Type | Mechanical |
| GPM @ 10 Feet of Head | 42.000 |
| GPM @ 20 Feet of Head | 39.000 |
| GPM @ 30 Feet of Head | 36.000 |
| GPM @ 40 Feet of Head | 32.000 |
| GPM @ 50 Feet of Head | 28.000 |
| GPM @ 70 Feet of Head | 14.000 |
| Shut Off Feet (Feet) | 82 |
