Brand: Sandvik Coromant / Part #: 8330232
Item #: 67611178
Brand: Sandvik Coromant
Model #: 8330232
Product Specifications
| Tap Type | Straight Flute |
| Thread Size (mm) | M14x1.25 |
| Thread Limit | D8 |
| Class Of Fit | 6HX |
| Number Of Flutes | 3 |
| Chamfer | Bottoming |
| Material | HSS-E-PM |
| Coating/Finish | DLC |
| Threads per Inch | 20 |
| Thread Direction | Right Hand |
| Coolant Through | Yes |
| Thread Standard | M |
| Overall Length (mm) | 100.0000 |
| Thread Pitch (mm) | 1.25 |
| Thread Length (mm) | 21.00 |
| Thread Depth (mm) | 21.00 |
| Application | Through & Blind Hole Threading; Tapping; Automotive |
| Shank Diameter (mm) | 11.0000 |
| Tapping Depth (mm) | 50.00 |
| Material Application | Non-Ferrous Metal |
| Series | CoroTap? 100 |
