Accurate Bushing - 13mm Roller Diam x 9mm Width, 5mm Stud Diam x 13mm Length, Stud Cam Follower - Carbon Steel, 7.5mm Thread Length, M5 x 0.8 Thread, 23mm OAL, 4,600 N Dynamic Cap, 3,400 N Static Cap
Item #: 55246920
Brand: Accurate Bushing
Model #: MCRV-13
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Stud Cam Follower |
| Roller Diameter (mm) | 13.000 |
| Roller Width (mm) | 9 |
| Stud Diameter (mm) | 5.00 |
| Dynamic Load Capacity (N) | 4600 |
| Static Load Capacity | 3400 |
| Length (mm) | 23.00 |
| Thread Size | M5 x 0.8 |
| Material | Carbon Steel |
| Stud Length (mm) | 13.00 |
| Thread Length (mm) | 7.50 |
| Roller Type | Full Complement |
