Accurate Bushing - 35mm Roller Diam x 18mm Width, 16mm Stud Diam x 32.5mm Length, Sealed Stud Cam Follower with Hex - Carbon Steel, 17mm Thread Length, M16 x 1.5 Thread, 52mm OAL, 12,900 N Dynamic Cap, 19,000 N Static Cap
Item #: 55246771
Brand: Accurate Bushing
Model #: MCR-35-SB
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Stud Cam Follower with Hex |
| Roller Diameter (mm) | 35.000 |
| Roller Width (mm) | 18 |
| Stud Diameter (mm) | 16.00 |
| Dynamic Load Capacity (N) | 12900 |
| Static Load Capacity | 19000 |
| Length (mm) | 52.00 |
| Thread Size | M16 x 1.5 |
| Material | Carbon Steel |
| Stud Length (mm) | 32.50 |
| Thread Length (mm) | 17.00 |
| Roller Type | Caged Roller |
