Accurate Bushing - 2-1/2" Roller Diam x 1-1/2" Width, 1" Stud Diam x 2-1/4" Length, Stud Cam Follower - Carbon Steel, 1-1/8" Thread Length, 1-14 Thread, 3-3/4" OAL, 15,280 Lb Dynamic Cap
Item #: 55229819
Brand: Accurate Bushing
Model #: CR-2-1/2
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Stud Cam Follower |
| Roller Diameter (Decimal Inch) | 2.5000 |
| Roller Diameter (Inch) | 2-1/2 |
| Roller Width (Decimal Inch) | 1.5000 |
| Stud Diameter (Decimal Inch) | 1.0000 |
| Dynamic Load Capacity (Lb.) | 15280 |
| Static Load Capacity (Pounds) | 0.00 |
| Length (Decimal Inch) | 3.750 |
| Thread Size | 1-14 |
| Material | Carbon Steel |
| Stud Length (Decimal Inch) | 2.2500 |
| Stud Length (Inch) | 2-1/4 |
| Thread Length (Inch) | 1-1/8 |
