US Motors - 1/4 hp, OAO Enclosure, Auto Thermal Protection, 1,075 RPM, 230 Volt, 60 Hz, Industrial Electric AC/DC Motor - Size 48 Frame, Stud Mount, 2 Speed, Sleeve Bearings, 2.0 Full Load Amps, B Class Insulation, Reversible
Item #: 53657490
Brand: US Motors
Model #: 8009
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type of Enclosure | OAO |
| Horsepower | 1/4 |
| Thermal Protection Rating | Auto |
| Name Plate RPMs | 1075 |
| Voltage | 230 |
| Frequency Hz | 60 |
| Frame Size | 48 |
| Mount Type | Stud |
| Number of Speeds | 2 |
| Bearing Type | Sleeve |
| Full Load Amperage | 2.0 |
| Insulation Class | B |
| Full Load Efficiency Rating | 57.30 |
| Motor Run Capacitor Micro Farid | 5.00 |
| Motor Run Capacitor Volts | 0 |
| Service Factor Rating | 1.00 |
| Motor Rotation | Reversible |
| PSC Code | 6105 |
