Mubea - 72mm ID, Grade 51CrV4 Chrome Vanadium Steel, Phosphate & Oil Finish, Belleville Disc Spring - 140mm OD, 11.2mm High, 7.5mm Thick
Item #: 53123238
Brand: Mubea
Model #: 190007
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| System of Measurement | Metric |
| Inside Diameter (mm) | 72.00 |
| Material | Chrome Vanadium Steel |
| Material Grade | 51CrV4 |
| Outside Diameter (mm) | 140.00 |
| Thickness (mm) | 7.50 |
| Overall Height (mm) | 11.20 |
| Deflection (mm) | 2.4 |
| Deflection to Flat (mm) | 3.20 |
| Load at Flat (N) | 123137.00 |
| Load at Deflection (N) | 85251.00 |
| Finish/Coating | Phosphate & Oil |
| Hardness | Rockwell C42-C52 |
