Iscar - Arbor Hole Connection, 1.1811" Depth of Cut, 100mm Cutter Diam, 0.8661" Hole Diam, 10 Tooth Indexable Slotting Cutter - SGSF Toolholder, GSF. Insert
Item #: 52733938
Brand: Iscar
Model #: 2300951
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Maximum Depth of Cut (mm) | 30.00 |
| Maximum Depth of Cut (Decimal Inch) | 1.1811 |
| Cutter Diameter (mm) | 100.00 |
| Cutter Diameter (Decimal Inch) | 3.9370 |
| Hole Diameter (mm) | 22.00 |
| Hole Diameter (Decimal Inch) | 0.8661 |
| Number of Teeth | 10 |
| Toolholder Style | SGSF |
| Series | Self-Grip(SGSA) |
| Insert Style | GSF. |
| Staggered Tooth | No |
| Insert Holding Method | Self Clamping |
| Maximum RPM | 800 |
| Minimum Cutting Width (Decimal Inch) | 0.0709 |
| Maximum Cutting Width (Decimal Inch) | 0.1059 |
| Maximum Cutting Width (mm) | 2.69 |
| Hub Diameter (mm) | 39.00 |
| Hub Diameter (Decimal Inch) | 1.5354 |
