Portable Hydraulic Cylinders; Actuation: Single Acting; Load Capacity: 34; Stroke Length: 11.81; Oil Capacity: 80.88; Cylinder Bore Diameter (Decimal Inch): 2.95; Cylinder Effective Area: 1; Lowered Height: 15.94
Item #: 72646458
Brand: Enerpac
Model #: RCL3012
Product Specifications
| Actuation | Single Acting |
| Load Capacity | 34 |
| Stroke Length | 11.81 |
| Oil Capacity | 80.88 |
| Cylinder Bore Diameter (Decimal Inch) | 2.95 |
| Cylinder Effective Area | 1 |
| Lowered Height | 15.94 |
| Retracted Length | 16 |
| Extended Length | 27.76 |
| Cushion Type | No Cushion |
| Bore Diameter | 2.9500 |
| Outside Diameter | 3.94 in |
| Maximum Working Pressure | 10150.000 |
| Body Material | Steel |
| Saddle Diameter | 1.97 |
| Series | RCL |
| Maximum Height (Inch) | 27.7600 |
| UNSPSC Code | 27121602 |
| Actuation | Single Acting |
| Load Capacity | 34 |
| Stroke Length | 11.81 |
| Oil Capacity | 80.88 |
| Cylinder Bore Diameter (Decimal Inch) | 2.95 |
| Cylinder Effective Area | 1 |
| Lowered Height | 15.94 |
| Retracted Length | 16 |
| Extended Length | 27.76 |
| Cushion Type | No Cushion |
| Bore Diameter | 2.9500 |
| Outside Diameter | 3.94 in |
| Maximum Working Pressure | 10150.000 |
| Body Material | Steel |
| Saddle Diameter | 1.97 |
| Series | RCL |
| Maximum Height (Inch) | 27.7600 |
| UNSPSC Code | 27121602 |
| MSC Part # | 72646458 |
| Mfr Part # | RCL3012 |
| Country of Origin Country of Origin is subject to change | Spain |
