Associated Spring Raymond - 5/8" Hole Diam, 11/32" Rod Diam, 3-1/2" Free Length, Green Die Spring - 109 Lb Max Deflection, 2.1417" Max Deflection, Light Duty, Chromium Alloy Steel
Item #: 52383270
Brand: Associated Spring Raymond
Model #: 303-314-D
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hole Diameter (Inch) | 5/8 |
| Rod Diameter (Inch) | 11/32 |
| Free Length (Inch) | 3-1/2 |
| Load Type | Light-Duty |
| Color | Green |
| Maximum Deflection Load (N) | 484.86 |
| Maximum Deflection Load (Lb.) | 109.00 |
| Maximum Deflection (mm) | 54.40 |
| Maximum Deflection (Decimal Inch) | 2.1417 |
| Wire Shape | Trapezoidal |
| Material | Chromium Alloy Steel |
| ISO Number | 10243 |
