Associated Spring Raymond - 1/2" Hole Diam, 9/32" Rod Diam, 3" Free Length, Green Die Spring - 66 Lb Max Deflection, 1.9606" Max Deflection, Light Duty, Chromium Alloy Steel
Item #: 52370608
Brand: Associated Spring Raymond
Model #: 303-212-D
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hole Diameter (Inch) | 1/2 |
| Rod Diameter (Inch) | 9/32 |
| Free Length (Inch) | 3 |
| Load Type | Light-Duty |
| Color | Green |
| Maximum Deflection Load (N) | 293.58 |
| Maximum Deflection Load (Lb.) | 66.00 |
| Maximum Deflection (mm) | 49.80 |
| Maximum Deflection (Decimal Inch) | 1.9606 |
| Wire Shape | Trapezoidal |
| Material | Chromium Alloy Steel |
| ISO Number | 10243 |
