Square End Mill: 1-1/4" Dia, 1-3/8" LOC, 6 Flute, High Speed Steel
Item #: 67148593
Brand: Cleveland
Model #: C75054
Product Specifications
| Mill Diameter (mm) | 31.75 |
| Mill Diameter (Decimal Inch) | 1.2500 |
| Mill Diameter (Inch) | 1-1/4 |
| Number Of Flutes | 6 |
| End Mill Material | High Speed Steel |
| Length of Cut (Decimal Inch) | 1.3750 |
| Length of Cut (Inch) | 1-3/8 |
| Length of Cut (mm) | 34.92 |
| Shank Diameter (mm) | 19.05 |
| Shank Diameter (Inch) | 3/4 |
| Shank Diameter (Decimal Inch) | 0.7500 |
| Overall Length (mm) | 92.07 |
| Overall Length (Decimal Inch) | 3.6250 |
| Overall Length (Inch) | 3-5/8 |
| Single Or Double End | Single |
| Coating/Finish Family | TiN |
| Centercutting | Yes |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
| Extended Reach | No |
| Coolant Through | No |
| Helix Angle | 30 |
| Primary Workpiece Material | Aluminum & Non-Ferrous; Cast Iron; Steel |
| Primary Workpiece Material Code | P; K; N |
| Coating/Finish | TiN |
| Variable Helix | No |
| Variable Index | No |
| Chipbreaker | No |
| Flute Type | Spiral |
| Shank Type | Weldon Flat |
| Material Grade | High-Speed Steel |
| Length Type | Stub |
| Series | HG-4C-TN |
| System Of Measurement | Fractional Inch |
| UNSPSC Code | 27112803 |
| Mill Diameter (mm) | 31.75 |
| Mill Diameter (Decimal Inch) | 1.2500 |
| Mill Diameter (Inch) | 1-1/4 |
| Number Of Flutes | 6 |
| End Mill Material | High Speed Steel |
| Length of Cut (Decimal Inch) | 1.3750 |
| Length of Cut (Inch) | 1-3/8 |
| Length of Cut (mm) | 34.92 |
| Shank Diameter (mm) | 19.05 |
| Shank Diameter (Inch) | 3/4 |
| Shank Diameter (Decimal Inch) | 0.7500 |
| Overall Length (mm) | 92.07 |
| Overall Length (Decimal Inch) | 3.6250 |
| Overall Length (Inch) | 3-5/8 |
| Single Or Double End | Single |
| Coating/Finish Family | TiN |
| Centercutting | Yes |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
| Extended Reach | No |
| Coolant Through | No |
| Helix Angle | 30 |
| Primary Workpiece Material | Aluminum & Non-Ferrous; Cast Iron; Steel |
| Primary Workpiece Material Code | P; K; N |
| Coating/Finish | TiN |
| Variable Helix | No |
| Variable Index | No |
| Chipbreaker | No |
| Flute Type | Spiral |
| Shank Type | Weldon Flat |
| Material Grade | High-Speed Steel |
| Length Type | Stub |
| Series | HG-4C-TN |
| System Of Measurement | Fractional Inch |
| UNSPSC Code | 27112803 |
| MSC Part # | 67148593 |
| Mfr Part # | C75054 |
| Country of Origin Country of Origin is subject to change | UNITED STATES |
