Kyocera - 3-3/4" Max Drill Depth, 5xD, 3/4" Diam, Indexable Insert Drill - 2 Inserts, 1" Shank Diam, Whistle Notch Shank
Item #: 50447697
Brand: Kyocera
Model #: 8837207
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Drill Style | DRX |
| Drill Diameter (Decimal Inch) | 0.7500 |
| Maximum Drill Depth (Decimal Inch) | 3.7500 |
| Shank Type | Whistle Notch |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Cutting Direction | Right Hand |
| Through Coolant | Through Coolant |
| Drill Depth by Diameter Ratio | 5xD |
| Insert Size (Decimal Inch) | 0.3390 |
| Number of Drill Inserts | 2 |
| Maximum Drill Diameter (Decimal Inch) | 0.7500 |
| Overall Length/Projection (Decimal Inch) | 6.7200 |
| Insert Compatibility | ZXMT 06T204SM |
| Body Length (Decimal Inch) | 4.5900 |
| Shank Length (Decimal Inch) | 2.1300 |
| Collar Diameter (Decimal Inch) | 1.2600 |
| Series | Magic Drill |
