Ball End Mill: 3 Flute(s), Solid Carbide
Item #: 40322141
Brand: YG-1
Model #: 38593
Product Specifications
| Mill Diameter (Inch) | 1/2 |
| Number Of Flutes | 3 |
| End Mill Material | Solid Carbide |
| End Type | Single |
| Length of Cut (Inch) | 3/4 |
| Coating/Finish | Bright/Uncoated |
| Overall Length (Inch) | 3-1/2 |
| Shank Diameter (Inch) | 1/2 |
| Extended Reach | Yes |
| Variable Helix | No |
| Variable Index | No |
| Helix Angle | 40 |
| Chipbreaker | No |
| Length Type | Long |
| Shank Diameter (Decimal Inch) | 0.5000 |
| Neck Diameter (Decimal Inch) | 0.4760 |
| Neck Length (Decimal Inch) | 1.3750 |
| Mill Diameter Tolerance | 0.0000 to -0.0012 in |
| Shank Diameter Tolerance | 0.0000 to -0.0003 in |
| Primary Workpiece Material | Non-Ferrous Metal |
| Primary Workpiece Material Code | N |
| Material Grade | Micrograin |
| Flute Direction | Right Hand |
| Cutting Direction | Right Hand |
| Series | E5975 |
| Flute Type | Spiral |
| UNSPSC Code | 27112803 |
| Shank Type | Straight-Cylindrical |
| Measurement Type | Fractional Inch |
