Sandvik Coromant - TNMX440901 MR Grade 2025 Carbide Turning Insert - TiCN/Al2O3/TiN Finish, 60° Triangle, 1" Inscr Circle, 3/8" Thick, 0.1mm Corner Radius
Item #: 49456726
Brand: Sandvik Coromant
Model #: 5754762
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | TNMX |
| Insert Size | 440901 |
| Material | Carbide |
| Length (mm) | 43.99 |
| Length (Decimal Inch) | 1.7319 |
| Inscribed Circle (mm) | 25.40 |
| Inscribed Circle (Decimal Inch) | 1.0000 |
| Inscribed Circle (Inch) | 1 |
| Thickness (Inch) | 3/8 |
| Thickness (Decimal Inch) | 0.3748 |
| Thickness (mm) | 9.52 |
| Corner Radius (mm) | 0.10 |
| Corner Radius (Decimal Inch) | 0.0039 |
| Manufacturer's Grade | 2025 |
| Coating | TiCN/Al2O3/TiN |
| Chip Breaker | MR |
| Hole Diameter (mm) | 7.93 |
| Hole Diameter (Decimal Inch) | 0.3122 |
| ISO Number | TNMX440901MR2025 |
| Relief Angle | 0 |
| Coating Process | MTCVD |
| Manufacturers Catalog Number | 5754762 |
| Primary Workpiece Material | M |
| Included Angle | 60 |
| Cutting Direction | Neutral |
| Insert Hand | Neutral |
| Maximum Depth of Cut (mm) | 14.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.5512 |
| Insert Holding Method | Pin & Clamp |
| Shape | Triangle |
