VFBS-216 1" ID, 2-3/4" OAL x 4-3/4" OAH Flange Bracket
Item #: 04716130
Brand: Browning
Model #: 764425
Product Specifications
| Bearing Insert Type | Ball |
| Type | Flange Bracket |
| Flange Mount Type | 3-Bolt Flange |
| Inside Diameter (Inch) | 1 |
| Bolt Hole (Center-to-center) | 2.5 in |
| Bolt Size (Inch) | 13/32 |
| Width (Inch) | 1-1/2 |
| Lubrication | Required |
| Housing Material | Iron |
| Overall Length (Inch) | 2-3/4 |
| Overall Height (Inch) | 4-3/4 |
| Lock Type | Set Screw Lock |
| Static Load Capacity | 1651.0 |
| Dynamic Load Capacity (Lb.) | 2801 |
| Base-to-center Distance | 0.813 in |
| Maximum RPM | 5500 |
| Series | VFBS 200 |
| Distance Between Mounting Hole Centers | 1-5/8 |
| Distance Between Base And Center (Inch) | 3-3/8 |
| Distance Between Base And Center (Decimal Inch) | 3.3750 |
| Insert Material | 52100 Steel |
| UNSPSC Code | 31171500 |
| Bearing Length (Inch) | 1-1/2 |
| Bearing Insert Type | Ball |
| Type | Flange Bracket |
| Flange Mount Type | 3-Bolt Flange |
| Inside Diameter (Inch) | 1 |
| Bolt Hole (Center-to-center) | 2.5 in |
| Bolt Size (Inch) | 13/32 |
| Width (Inch) | 1-1/2 |
| Lubrication | Required |
| Housing Material | Iron |
| Overall Length (Inch) | 2-3/4 |
| Overall Height (Inch) | 4-3/4 |
| Lock Type | Set Screw Lock |
| Static Load Capacity | 1651.0 |
| Dynamic Load Capacity (Lb.) | 2801 |
| Base-to-center Distance | 0.813 in |
| Maximum RPM | 5500 |
| Series | VFBS 200 |
| Distance Between Mounting Hole Centers | 1-5/8 |
| Distance Between Base And Center (Inch) | 3-3/8 |
| Distance Between Base And Center (Decimal Inch) | 3.3750 |
| Insert Material | 52100 Steel |
| UNSPSC Code | 31171500 |
| Bearing Length (Inch) | 1-1/2 |
| MSC Part # | 04716130 |
| Mfr Part # | 764425 |
| Country of Origin Country of Origin is subject to change | Mexico |
