Kyocera DR1875, HOLESHOT Drill 1.8750″ Cutting Diameter, 1.2500″ Shank Diameter, Coolant-Through Indexable Insert Drill
Item #: 44403459
Brand: Kyocera
Model #: OTM86273
Product Specifications
| Drill Style | HD |
| Drill Diameter (Decimal Inch) | 1.8750 |
| Maximum Drill Diameter (Decimal Inch) | 1.8750 |
| Drill Diameter (Inch) | 1-7/8 |
| Maximum Drill Depth (Decimal Inch) | 3.3800 |
| Shank Type | Weldon |
| Shank Diameter (Inch) | 1-1/4 |
| Number of Drill Inserts | 4 |
| Drill Diameter Range (Decimal Inch) | 1.5000 to 2.0000 |
| Cutting Direction | Right Hand |
| Maximum Drill Depth Range (Decimal Inch) | 3.0000 to 4.0000 |
| Tool Material | Steel |
| Compatible Insert Style | WCMX |
| Drill Depth by Diameter Ratio | 2xD |
| Series | HD |
| Body Length (Decimal Inch) | 4.5000 |
| Shank Length (Decimal Inch) | 2.2800 |
| Overall Length/Projection (Decimal Inch) | 6.7800 |
| Insert Compatibility | WCMX050308-M1A?; WCMX050308-M1? |
| Extension From Holder (Inch) | 4.5000 |
| Coolant Through | Yes |
