Associated Spring Raymond - 1/4" Bolt, Grade 17-7 PH Stainless Steel, Uncoated, Belleville Disc Spring - 0.042" High, 0.014" Thick
Item #: 41930330
Brand: Associated Spring Raymond
Model #: BC0500014S
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Bolt Size (Inch) | 1/4 |
| Bolt Size (mm) | 6.35 |
| System of Measurement | Inch |
| Material | Stainless Steel |
| Material Grade | 17-7 PH |
| Thickness (mm) | 0.36 |
| Thickness (Decimal Inch) | 0.0140 |
| Overall Height (mm) | 1.07 |
| Overall Height (Decimal Inch) | 0.0420 |
| Deflection (Decimal Inch) | 0.0210 |
| Deflection (mm) | 0.53 |
| Minimum Inside Diameter (Decimal Inch) | 0.2550 |
| Minimum Inside Diameter (mm) | 6.48 |
| Maximum Outside Diameter (Decimal Inch) | 0.5000 |
| Maximum Outside Diameter (mm) | 12.70 |
| Load at Flat (Lb.) | 36.00 |
| Load at Flat (N) | 160.14 |
| Minimum Load at Deflection (Lb.) | 21.10 |
| Minimum Load at Deflection (N) | 93.86 |
| Maximum Load at Deflection (Lb.) | 31.60 |
| Maximum Load at Deflection (N) | 140.56 |
| Finish/Coating | Uncoated |
| Bolt Size (Decimal Inch) | 1/4 |
