Indexable Turning Toolholder: ACLNL16-4-CHP-MC, 95.000 deg Lead Angle, Clamp
Item #: 82262387
Brand: Tungaloy
Model #: 3346691
Product Specifications
| Toolholder Style | ACLN |
| Hand of Holder | Left Hand |
| Lead Angle | 95.000 |
| Insert Compatibility | CN..43. |
| Insert Holding Method | Clamp |
| Shank Width (Inch) | 1 |
| Shank Height (Inch) | 1 |
| Overall Length (Decimal Inch) | 6.0000 |
| Rake | Negative |
| Cutting Direction | Left Hand |
| Compatible Insert Size Code | CN..43. |
| Rake Angle | 6 |
| Multi-use Tool | Yes |
| Shank Width (Decimal Inch) | 1.0000 |
| Shank Height (Decimal Inch) | 1.0000 |
| Series | ACLN |
| Overall Length (Inch) | 6 |
| Cutting Tool Application | Facing; Turning |
| Head Length (Decimal Inch) | 1.3780 |
| Back of Bar to Cutting Edge (Inch) | 1-1/4 |
| Primary Workpiece Material | Universal |
| Insert Inscribed Circle (Inch) | 1/2 |
| Toolholder Material | Steel |
| UNSPSC Code | 23153308 |
| Insert Thickness (Decimal Inch) | 0.1870 |
| Country of Origin | Israel |
