Kennametal - 25mm Max Drill Depth, 2xD, 1/2" Diam, Indexable Insert Drill - 2 Inserts, 20mm Shank Diam, Straight Shank
Item #: 37970894
Brand: Kennametal
Model #: 6079779
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Drill Style | DFR |
| Drill Diameter (Inch) | 1/2 |
| Drill Diameter (Decimal Inch) | 0.5000 |
| Maximum Drill Depth (mm) | 25.00 |
| Shank Type | Straight Shank |
| Shank Diameter (mm) | 20.00 |
| Cutting Direction | Right Hand |
| Through Coolant | Through Coolant |
| Drill Depth by Diameter Ratio | 2xD |
| Toolholder Material | Steel |
| Number of Drill Inserts | 2 |
| Maximum Drill Diameter (mm) | 13.70 |
| Overall Length/Projection (mm) | 97.40 |
| Insert Compatibility | DFR0202.. |
| Flute Length (mm) | 30.00 |
| Body Length (mm) | 47.40 |
| Shank Length (mm) | 50.00 |
