Brand: Bison / Part #: 7-148-360
Item #: 90898032
Brand: Bison
Model #: 7-148-360
Product Specifications
| Modular Connection Size | C3 |
| Overall Length (Decimal Inch) | 2.4300 |
| Overall Length (mm) | 61.7200 |
| Maximum RPM | 25000.000 |
| Projection Flange to Nose End (Decimal Inch) | 2.4300 |
| Projection Flange to Nose End (mm) | 61.72 |
| Taper Size | C3 |
| Pilot Diameter (Decimal Inch) | 0.7500 |
| Pilot Diameter (Inch) | 3/4 |
| Nose Diameter (Mm) ( - 2 Decimals) | 44.45 |
| Nose Diameter (Decimal Inch - 4 Decimals) | 1.7500 |
| Through Coolant | Yes |
| TIR (mm) | 0.0050 |
| TIR (Decimal Inch) | 0.000200 |
| Overall Height (Decimal Inch) | 3.1800 |
| Arbor Hole Diameter (Decimal Inch) | 0.7500 |
| Balanced To Rpm | 25000 |
| Gage Overall Length (mm) | 61.72 |
| Overall Height (Mm - 5 Decimals) | 80.77000 |
| Gage Overall Length (Decimal Inch) | 2.4300 |
