Brand: Seco / Part #: 10128065
Item #: 67252155
Brand: Seco
Model #: 10128065
Product Specifications
| Minimum Cutting Diameter (Decimal Inch) | 2.5000 |
| Maximum Cutting Diameter (Decimal Inch) | 2.5000 |
| Maximum Depth of Cut (Decimal Inch) | 3.1370 |
| Cutter Style | R217.82 |
| Shank Type | Modular Connection |
| Shank Diameter (Decimal Inch) | 2.4803 |
| Maximum Ramping Angle | 1.7 |
| Insert Holding Method | Screw |
| Shank Taper Size | C6 |
| Overall Length (Decimal Inch) | 6.0236 |
| Tool Material | Steel |
| Series | R217.82 |
| Flute Type | Helical |
| Lead Angle | 90 |
| Shank Length (Decimal Inch) | 1.4961 |
| Head Length (Decimal Inch) | 3.6299 |
| Modular Connection Size | C6 |
| Maximum RPM | 7400.000 |
| Tool Application | Milling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| End Mill Type | Helical End Mill |
| Rake | Negative |
| Complete Insert Compatibility | SN..16.. |
| MSC/Manufacturer Number | C6-R217.82-2.5-3.11-SNXO16.4SA |
| Hand of Holder | Right Hand |
| Multi-Use Tool | Yes |
| ISO Number | C6-R217.82-2.5-3.11-SNXO16.4SA |
| Number Of Flutes | 4 |
| Usable Length (Decimal Inch) | 3.6299 |
| Number Of Cutter Inserts | 28 |
| Coolant Through | Yes |
