Barksdale - 0.72 GPM 3/8 Inlet Anodized Aluminum Hydraulic Control Valve - 3/8 Thread, 6,000 psi, 3" High x 2.03" Wide x 4.11" Long, 0.09 CV Rate
Item #: 31075898
Brand: Barksdale
Model #: 52641M6HC3
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Hydraulic Control Valves |
| GPM | 0.72 |
| Length (Decimal Inch) | 4.110 |
| Width (Decimal Inch) | 2.0300 |
| Material | Anodized Aluminum |
| Height (Inch) | 3 |
| Maximum Working Pressure (psi) | 6000.00 |
| Inlet Size | 3/8 |
| Number of Positions | 3 |
| Number of Positions | 3 Position |
| Thread Size | 0.375 |
| CV Rating | 0.090 |
| Thread Type | D03 Manifold Mounting |
| Seal Material | Stainless Steel |
| Description | 4-Way Closed Center; 3-Position Detent |
| Outlet Size (Inch) | 3/8 |
