Iscar - Neutral Cut, Size C5, LNMX 1506.. Insert Compatiblity, Internal or External Modular Turning & Profiling Cutting Unit Head - 50.01mm Head Length, Through Coolant, Series CAMFIX & Isoturn
Item #: 30710156
Brand: Iscar
Model #: 3602480
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| System Size | C5 |
| Series Name | CAMFIX; Isoturn |
| Cutting Direction | Neutral |
| Head Length/Projection (mm) | 50.01 |
| Head Length/Projection (Decimal Inch) | 1.9690 |
| Insert Style | LNMX 1506.. |
| Internal or External | Internal or External |
| Insert Holding Method | Screw |
| Through Coolant | Through Coolant |
| Complete Insert Compatibility | VCGT 33-.004-AS; VCGT 330-AS; VCGT 331-AS; VCGT 331D; VCGT 332-AS; VCGT 332D; VCGT 333-AS; VCMT 330-SM; VCMT 331-14; VCMT 331-SM; VCMT 331T; VCMT 332-14; VCMT 332-SM; VCMT 333-SM; VCMW 331 |
