Walter-Titex - Left Hand Cut, 95° Lead Angle, 12mm Shank Height x 12mm Shank Width, Negative Rake Indexable Turning Toolholder - 120mm OAL
Item #: 30307052
Brand: Walter-Titex
Model #: 6712855
Exact Tooling IR#: 04
Features and Benefits
Aluminum chromium nitride (AlCrN) has higher-heat resistance than AlTiN. It is commonly used for machining aircraft and aerospace material, nickel alloys, stainless steel, titanium, cast iron and carbon steel.
| Product Specifications | |
|---|---|
| Hand of Holder | Left Hand |
| Rake | Negative |
| Lead Angle | 95 |
| Shank Width (mm) | 12.00 |
| Shank Width (Decimal Inch) | 0.4720 |
| Shank Height (mm) | 12.00 |
| Shank Height (Decimal Inch) | 0.4720 |
| Overall Length (mm) | 120.00 |
| Overall Length (Decimal Inch) | 4.7240 |
| Insert Holding Method | Screw |
| Head Length (mm) | 11.00 |
| Head Length (Decimal Inch) | 0.4330 |
| Drill Bit Material | Carbide |
| Series/List | DB133-05-A0 |
| Drill Bit Finish/Coating | AlCrN |
| Cutting Direction | Right Hand |
| Maximum Drilling Depth (mm) | 7.00 |
| Material Grade | Carbide |
| Flute Length (mm) | 9.00 |
| Flute Length (Decimal Inch) | 0.354 |
| Drill Point Angle | 140 |
| Drill Bit Size (Decimal Inch) | 0.0433 |
| Drill Bit Size (mm) | 1.1 |
| Through Coolant | No |
| Shank Diameter (mm) | 3 |
| Shank Diameter (Inch) | 0.118 |
| Overall Length (mm) | 51 |
| Overall Length (Decimal Inch) | 2.008 |
