Turning Insert: CNMM43XLSX PR115S, Carbide
Item #: 74840687
Brand: Kyocera
Model #: TLV00032
Product Specifications
| ANSI Insert Code | CNMM43X |
| ISO Insert Code | CNMM1204X |
| Relief Angle | 0 |
| Insert Style | CNMM |
| Corner Radius (mm) | 0.00 |
| Corner Radius (Decimal Inch) | 0.0000 |
| Included Angle | 80 |
| Manufacturer Grade | PR115S |
| Coating/Finish | MEGACOAT TOUGH |
| Wiper Edge | No |
| Insert Hand | Left Hand |
| Insert Thickness (Inch) | 3/16 |
| Insert Thickness | 4.76 |
| Insert Thickness (Decimal Inch) | 0.1874 |
| Series | ISO Insert |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Inscribed Circle (Inch) | 1/2 |
| Inscribed Circle (mm) | 12.70 |
| Insert Material | Carbide |
| Insert Shape | C - Diamond (Rhombic) 80-Deg |
| Chip Breaker Operation | Medium Machining; Roughing |
| Grade Characteristics | Special, Super Alloys (S) - High Wear-Resistance to Moderate Wear-Resistance and Toughness |
| Side Clearance | Negative |
| Number Of Cutting Edges | 2 |
| Insert Shape Code | C |
| Hole Diameter (Decimal Inch) | 0.2032 |
| Hole Diameter (Mm) ( - 0 Decimals) | 5.16 |
| Insert Holding Method | Screw; Clamp |
| Clearance Code | N |
| Tolerance Code | M |
| Coating Process | PVD |
| Rake | Negative |
| Primary Workpiece Material | Heat-Resistant Alloy |
| Primary Workpiece Material Code | S |
| Secondary Workpiece Material Code | None |
| Iso Code | CNMM1204XL-SX |
| Manufacturers Catalog Number | CNMM43XLSXPR115S |
| Chip Breaker | SX |
| Multi-Use Tool | Yes |
| Multi-Use Application | External Turning; Facing; Internal Facing; Boring |
| ANSI Size Code | 43X |
| ISO Size Code | 1204X |
| UNSPSC Code | 23242107 |
| Insert Size Code | 43 |
| ANSI Insert Code | CNMM43X |
| ISO Insert Code | CNMM1204X |
| Relief Angle | 0 |
| Insert Style | CNMM |
| Corner Radius (mm) | 0.00 |
| Corner Radius (Decimal Inch) | 0.0000 |
| Included Angle | 80 |
| Manufacturer Grade | PR115S |
| Coating/Finish | MEGACOAT TOUGH |
| Wiper Edge | No |
| Insert Hand | Left Hand |
| Insert Thickness (Inch) | 3/16 |
| Insert Thickness | 4.76 |
| Insert Thickness (Decimal Inch) | 0.1874 |
| Series | ISO Insert |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Inscribed Circle (Inch) | 1/2 |
| Inscribed Circle (mm) | 12.70 |
| Insert Material | Carbide |
| Insert Shape | C - Diamond (Rhombic) 80-Deg |
| Chip Breaker Operation | Medium Machining; Roughing |
| Grade Characteristics | Special, Super Alloys (S) - High Wear-Resistance to Moderate Wear-Resistance and Toughness |
| Side Clearance | Negative |
| Number Of Cutting Edges | 2 |
| Insert Shape Code | C |
| Hole Diameter (Decimal Inch) | 0.2032 |
| Hole Diameter (Mm) ( - 0 Decimals) | 5.16 |
| Insert Holding Method | Screw; Clamp |
| Clearance Code | N |
| Tolerance Code | M |
| Coating Process | PVD |
| Rake | Negative |
| Primary Workpiece Material | Heat-Resistant Alloy |
| Primary Workpiece Material Code | S |
| Secondary Workpiece Material Code | None |
| Iso Code | CNMM1204XL-SX |
| Manufacturers Catalog Number | CNMM43XLSXPR115S |
| Chip Breaker | SX |
| Multi-Use Tool | Yes |
| Multi-Use Application | External Turning; Facing; Internal Facing; Boring |
| ANSI Size Code | 43X |
| ISO Size Code | 1204X |
| UNSPSC Code | 23242107 |
| Insert Size Code | 43 |
| MSC Part # | 74840687 |
| Mfr Part # | TLV00032 |
| Country of Origin Country of Origin is subject to change | Japan |
