Circuit Breakers; Circuit Breaker Type: Miniature Circuit Breaker; Amperage: 30; Voltage: 120/240V; Wire Size (AWG): 14-8; Number Of Poles: 1; Tripping Mechanism: Thermal-Magnetic; Terminal Connection Type: Pressure Plate; Phase: Single
Item #: 93494540
Brand: Square D
Model #: QOB130VH1021
Product Specifications
| Circuit Breaker Type | Miniature Circuit Breaker |
| Amperage | 30 |
| Voltage | 120/240V |
| Wire Size (AWG) | 14-8 |
| Number Of Poles | 1 |
| Tripping Mechanism | Thermal-Magnetic |
| Terminal Connection Type | Pressure Plate |
| Phase | Single |
| Breaking Capacity | 22 kA |
| Mount Type | Bolt-On |
| Maximum Operating Temperature F | 140.000 |
| Minimum Operating Temperature F | 14.000 |
| Overall Length (Decimal Inch) | 2.9100 |
| Overall Width (Decimal Inch - 4 Decimals) | 1.5000 |
| Overall Height (Decimal Inch) | 2.9900 |
| Standards | CSA; UL Listed |
| UNSPSC Code | 39121603 |
