Vertical Bandsaws; Drive Type: Belt, Two-Step Pulley; Throat Capacity (Decimal Inch): 11.0000; Throat Capacity (Inch): 11; Throat Depth (Inch): 11; Height Capacity (Inch): 14.5; Phase: Three; Horsepower: 1.0000; Minimum Blade Speed: 70 FPM
Item #: 94199544
Brand: Dake
Model #: 988041-2
Product Specifications
| Drive Type | Belt; Two-Step Pulley |
| Throat Capacity (Decimal Inch) | 11.0000 |
| Throat Capacity (Inch) | 11 |
| Throat Depth (Inch) | 11 |
| Height Capacity (Inch) | 14.5 |
| Phase | Three |
| Horsepower | 1.0000 |
| Minimum Blade Speed | 70 FPM |
| Maximum Blade Speed | 540 FPM |
| Blade Width (Inch - 0 Decimals) | 1/4 - 3/4 |
| Blade Length (Feet) | 10.00 |
| Blade Length (Decimal Inch) | 120 |
| Blade Thickness (Inch) | 0.035 |
| Blade Wheel Diameter (Inch) | 14 |
| Blade Guide Type | Carbide; Ball Bearing; Aluminum Bronze |
| Coolant System | No |
| Capacity Under Guides | 14.5 |
| Floor to Table Height (Inch) | 36.5 |
| Table Length (Inch) | 29 |
| Table Width (Inch) | 18 |
| Table Feed Operation | Gravity |
| Frequency | 60 |
| Voltage | 220V |
| Base Width (Inch) | 40 |
| Base Depth (Inch) | 29 |
| Overall Height (Inch) | 66 |
| Overall Depth (Inch) | 40 |
| Overall Length (Inch) | 29 |
| Includes | Blade |
| Special Item Information | Rolling Frame |
| Warranty | 1 Year |
| Maximum Blade Working Height | 14.5 |
| Table Stroke | 9 |
| Number Of Slots | 1 |
| UNSPSC Code | 23231100 |
| Country of Origin | UNITED STATES |
