Gates - Belts Belt Style: Synchronous Belt Section: Round
Item #: 96341136
Brand: Gates
Model #: 90022089
Product Specifications
Belts; Belt Style: Synchronous ; Belt Section: Round ; Outside Length: 5.937 (Decimal Inch); Outside Length: 150.80 (mm); Belt Width: 0.375 (Decimal Inch); Belt Width: 9.53 (mm)
| Belt Style | Synchronous |
| Belt Section | Round |
| Outside Length (Decimal Inch) | 5.937 |
| Outside Length (mm) | 150.80 |
| Belt Width (Decimal Inch) | 0.375 |
| Belt Width (mm) | 9.53 |
| Belt Number | 60XL037 |
| Belt Internal Length (Decimal Inch) | 6.00 |
| Belt Internal Length (mm) | 152.40 |
| Number of Ribs | 0.000 |
| Number of Teeth | 30 |
| Belt Pitch | 5 mm |
| Material | Neoprene |
| Belt Height | 0.13 |
| Color | Black |
| Style | Synchronous |
| Maximum Temperature (F) | 180 |
