Techniks - CAT50 Taper Shank Tension & Compression Tapping Chuck - 1-7/16 to 1-7/8" Tap Capacity, 5.79" Projection, Quick Change
Item #: 19890813
Brand: Techniks
Model #: 32900/50CAT
Exact Tooling IR#: 04
Features and Benefits
Tension and compression tapping styles are engineered to automatically compensate for machine feed, pitch and tap rates. They feature a spring design that allows the tap to float during the cutting cycle without affecting the pitch.
Taper shanks maintain balance and rigidity during high speeds and heavy-duty applications. They have smaller diameters than straight shanks.
| Product Specifications | |
|---|---|
| Tapping Style | Tension & Compression |
| Shank Type | Taper Shank |
| Taper Size | CAT50 |
| Minimum Tap Capacity (Inch) | 1-7/16 |
| Maximum Tap Capacity (Inch) | 1-7/8 |
| Projection (Decimal Inch) | 5.7900 |
| Quick Change | Yes |
| Minimum Collet Capacity (mm) | M36 |
| Minimum Collet Capacity (Inch) | 1-1/2 |
| Maximum Collet Capacity (Inch) | 1-7/8 |
| Overall Length (Decimal Inch) | 9.7900 |
