Fairlane - 1/4-28, 0.2400" Thread Length, 1/2" Ball Diam, Alloy Steel, Black Oxide, Base, Swivel Action Gripper Assemblies - 5/8" Diam, 15/64" Deep Thread, 3/4" Overall Height, Stainless Steel Ball
Item #: 09718339
Brand: Fairlane
Model #: BBU-500
Exact Tooling IR#: 04
Features and Benefits
Alloy steel is the strongest of all steel types. It has high tensile strength and offers excellent resistance to wear, fatigue and galling.
| Product Specifications | |
|---|---|
| Assembly Type | Base |
| Thread Size | 1/4-28 |
| Ball Diameter (Inch) | 1/2 |
| Diameter (Inch) | 5/8 |
| Overall Height (Inch) | 3/4 |
| Thread Length (Decimal Inch) | 0.2400 |
| Degree of Swivel | 20 |
| Ball Material | Stainless Steel |
| Tap Size | 1/4-28 |
| Thread Depth (Inch) | 15/64 |
| Replaceable Pad | No |
| Load Rating (Lb.) | 5849.00 |
| Material | Alloy Steel |
| Finish/Coating | Black Oxide |
| Replacement Pad Diameter (Inch) | 3/8 |
| Replacement Pad Height (Inch) | 3/8 |
