Indexable Grooving Blades; Cutting Direction: Neutral; Minimum Groove Width: 3.00; Minimum Groove Width (Decimal Inch): 0.1182; Minimum Groove Width (mm): 3.00; Blade Style: Blade Holder; Minimum Insert Width (Decimal Inch): 0.1182; Minimum Insert Width (
Item #: 07074792
Brand: Accupro
Model #: 07074792
Product Specifications
| Cutting Direction | Neutral |
| Minimum Groove Width | 3.00 |
| Minimum Groove Width (Decimal Inch) | 0.1182 |
| Minimum Groove Width (mm) | 3.00 |
| Blade Style | Blade Holder |
| Minimum Insert Width (Decimal Inch) | 0.1182 |
| Minimum Insert Width (mm) | 3.00 |
| Blade Height (mm) | 26.00 |
| Blade Height (Decimal Inch) | 1.0236 |
| Blade Width (Decimal Inch) | 0.0945 |
| Blade Width (mm) | 2.40 |
| Maximum Depth of Cut (Decimal Inch) | 1.3800 |
| Maximum Depth of Cut (mm) | 35.00 |
| Minimum Workpiece Diameter (mm) | 3.00 |
| Maximum Workpiece Diameter (mm) | 3.00 |
| Maximum Insert Width (mm) | 3.00 |
| Maximum Insert Width (Decimal Inch) | 0.1181 |
| Compatible Insert Style | GO; GD |
| Compatible Insert Size Code | 3 |
| Series | CI |
| Overall Length (mm) | 110.0000 |
| Overall Length (Decimal Inch) | 4.3307 |
| Maximum Groove Width (Decimal Inch) | 0.1181 |
| Maximum Groove Width (mm) | 3.00 |
| Blade Overall Length (mm) | 110.00 |
| Blade Overall Length (Decimal Inch) | 4.3300 |
| Cutting Height (mm) | 26.00 |
| Cutting Height (Decimal Inch) | 1.0236 |
| Single Or Double End | Double |
| UNSPSC Code | 23241600 |
