Brand: Value Collection / Part #: 308-0232 F2AX
Item #: 71485775
Brand: Value Collection
Model #: 308-0232 F2AX
Product Specifications
| Phase | Three |
| Spindle Speed Control | Geared Head |
| Bed Width (Inch) | 14.0000 |
| Bed Width (Inch) | 14 |
| Bed Width | 14 in |
| Distance Between Centers (Inch) | 40 |
| Distance Between Centers | 40 in |
| Cross Slide Travel | 37.25 in |
| Gap Length (Decimal Inch) | 9.3750 |
| Gap Length | 9.375 in |
| Cross Slide Travel (Inch) | 37-1/4 |
| Swing | 14 in |
| Cross Slide Travel (Decimal Inch) | 37.2500 |
| Swing (Inch) | 14 |
| Spindle Bore Diameter (Inch) | 1-7/16 |
| Minimum Spindle Speed | 45 |
| Spindle Nose Designation | D1-4 |
| Maximum Spindle Speed | 1800 |
| Overall Height | 49.125 in |
| Overall Depth | 31 in |
| Minimum Metric Pitch (Decimal Inch) | 0.0177 |
| Number of Inch Threads | 40 |
| Minimum Metric Pitch | 0.0177 in |
| Spindle Taper Size | 5MT |
| Tailstock Taper Size | 3MT |
| Maximum Threads Per Inch | 112 |
| Min. Longitudinal Feed Per Rev. (Decimal Inch) | 0.0012 |
| Overall Depth (Inch) | 31 |
| Overall Length (Inch) | 71-3/4 |
| Max. Longitudinal Feed Per Rev. (Decimal Inch) | 0.0294 |
| Maximum Longitudinal Feed Per Revolution | 0.0294 in |
| Minimum Cross Feed Rate Per Revolution | 0.0003 in |
| Min. Cross Feed Rate Per Revolution (Decimal Inch) | 0.000300 |
| Max. Cross Feed Rate Per Revolution (Decimal Inch) | 0.0100 |
| Maximum Cross Feed Rate Per Revolution | 0.01 in |
| Swing Over Cross Slide (Decimal Inch) | 8.5000 |
| Swing Over Cross Slide (Inch) | 8-1/2 |
| Swing Over Gap (Inch) | 20 |
| Swing Over Gap (Decimal Inch) | 20.0000 |
| Swing Over Gap | 20 in |
