Interstate - 1-1/4" Diam Milling Machine Arbor - Style B, Taper Shank, NMTB50 Taper
Item #: 08242802
Brand: Interstate
Exact Tooling IR#: 04
Features and Benefits
Milling machine arbors are used for holding milling cutters and slitting saws. they can hole one or more milling cutters or saws with the use of arbor spacers and shims.
Style B arbors are designed with large bearing covers that can be positioned close to the cutter for maximum support. They do not have a pilot and are used for heavy duty applications.
| Product Specifications | |
|---|---|
| Type | Milling Machine Arbor |
| Milling Arbor Style | Style B |
| Shank Type | Taper Shank |
| Arbor Diameter (mm) | 31.75 |
| Arbor Diameter (Inch) | 1-1/4 |
| Arbor Diameter (Decimal Inch) | 1.2500 |
| Shank Diameter (mm) | 53.97 |
| Shank Diameter (Inch) | 2 |
| Shank Diameter (Decimal Inch) | 2.1250 |
| Taper Size | NMTB50 |
| Overall Length (mm) | 555.80 |
| Overall Length (Decimal Inch) | 21.8819 |
| Projection (mm) | 126.80 |
| Shoulder to Nut Length (Inch) | 15 |
| Drawbar Thread Size | 1-8 |
| Number of Bushings | 1 |
| Bushing Diameter (Inch) | 2-1/8 |
| Bushing Length (Inch) | 3-3/4 |
| Includes | Arbor Spacer; Running Bushing |
