Interstate - 1-1/4" Diam Milling Machine Arbor - Style A, Taper Shank, NMTB50 Taper
Item #: 08241929
Brand: Interstate
Exact Tooling IR#: 04
Features and Benefits
Milling machine arbors are used for holding milling cutters and slitting saws. they can hole one or more milling cutters or saws with the use of arbor spacers and shims.
Style A arbors are designed with a pilot on the end, allowing for maximum clearance along the arbor. They are commonly used on small horizontal milling machines.
| Product Specifications | |
|---|---|
| Type | Milling Machine Arbor |
| Milling Arbor Style | Style A |
| Shank Type | Taper Shank |
| Arbor Diameter (mm) | 31.75 |
| Arbor Diameter (Inch) | 1-1/4 |
| Arbor Diameter (Decimal Inch) | 1.2500 |
| Shank Diameter (mm) | 53.97 |
| Shank Diameter (Inch) | 2 |
| Shank Diameter (Decimal Inch) | 2.1250 |
| Taper Size | NMTB50 |
| Overall Length (mm) | 416.10 |
| Overall Length (Decimal Inch) | 16.3819 |
| Projection (mm) | 126.80 |
| Shoulder to Nut Length (Inch) | 8 |
| Number of Bushings | 0 |
| Includes | Arbor Spacer |
