Brand: Widia / Part #: 3870076
Item #: 98624620
Brand: Widia
Model #: 3870076
Product Specifications
| Cutting Direction | Neutral |
| Hand of Holder | Neutral |
| Compatible Insert Size Code | 1103.. |
| Toolholder Style | CTCPN |
| Rake | Positive |
| Rake Angle | 0 (Axial);0 (Radial) |
| Multi-use Tool | Yes |
| Lead Angle | 9.000 |
| Insert Holding Method | Clamp |
| Insert Compatibility | TP..1103.. |
| Shank Width (mm) | 10.00 |
| Shank Height (mm) | 25.00 |
| Series | CTCP |
| Overall Length (mm) | 150.0000 |
| Cutting Tool Application | Facing; Turning |
| Head Length (mm) | 25.91 |
| Back of Bar to Cutting Edge (mm) | 9.96 |
| Primary Workpiece Material | Universal |
| Insert Width (mm) | 6.35 |
| Toolholder Material | Steel |
| ISO Number | CTCPN2510M11 |
| Complete Insert Compatibility | TP.. |
| Insert Thickness | 3.18 |
| Coolant Through | No |
| Insert Inscribed Circle (mm) | 6.35 |
