Spur Gear: 14 Teeth, 3/16" Bore Dia
Item #: 03925054
Brand: Made in USA
Model #: 2414BI
Product Specifications
| Gear Type | Spur |
| Pitch Diameter (Decimal Inch) | 0.5830 |
| Outside Diameter (Decimal Inch - 4 Decimals) | 0.6670 |
| Face Width (Decimal Inch) | 0.2500 |
| Face Width (Inch) | 1/4 |
| Hub Diameter (Decimal Inch) | 0.3800 |
| Hub Diameter (Inch) | 7/16 |
| Pressure Angle | 20.0 |
| Material | POM |
| Diametral Pitch | 24 |
| Bore Diameter (Decimal Inch) | 0.1875 |
| Bore Diameter (Inch) | 3/16 |
| Number Of Teeth | 14 |
| UNSPSC Code | 31171700 |
| Product Service Code | 3020 |
