Gardner Spring - 0.18" OD, 0.026" Wire, 1/4" Free Length, Precision Compression Spring - 60 Lb Spring Rating, Music Wire
Item #: 02085413
Brand: Gardner Spring
Model #: 36018G
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Precision Compression |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Free Length (Decimal Inch) | 0.250 |
| Spring Rate Pounds per Inch (Pounds) | 60.0000 |
| Maximum Work Load (Pounds) | 6.7500 |
| Solid Height | 0.138 |
| Material | Music Wire |
| Wire Size (Decimal Inch) | 0.026 |
